Parameter

JYM14A&JYM25A

Parameter Value

Frequency Range

JYM14A：2 ~ 30 Mhz     JYM25A：2 ~ 200 Mhz

Frequency Accuracy

+/-0.5 PPM Max . ( Center Control Voltage )

Frequency Stability  vs Temperature

+/- 0.05 PPM ~ +/- 1 PPM

Aging

+/-1 PPM / year

Output Type

TTL / HCMOS / SINE

Supply Voltage

+3.3 V , + 5.0 VDC ，+ 9.0 VDC，12.0 VDC

Frequency Stability vs Load

+/- 0.1 PPM vs +/- 10% load change

Frequency Stability vs Voltage

+/- 0.1 PPM vs +/- 5 % voltage change

Supply Current

10 mA (Typical )

Adjustable Frequency Range

+/-3.0 PPM

Control Voltage Range

0 ~ 3.3 V / 0 ~ 5 V

Slope

Positive

Linearity

+/- 10%

Phase Noise (10Mhz )

1kHz , -130 dBc/ Hz

-50 ~ 90 ℃
