Voltage
Control Crystal Oscillators （JYV08A&JYV14A）
Configuration
Principal Parameters
Parameter
JYV08A&JYV14A
Parameter Value
FrequencyRange
1
~ 40 Mhz
Frequency
Accuracy
+/-15 PPM
Frequency
Stabilityvs
Temperature
+/-
10 PPM ~ +/- 50 PPM
Aging
+/-3
PPM / year
Output
Type
TTL
/ HCMOS
Supply
Voltage
+3.3
V , + 5.0 VDC
Supply
Current
< 20
M：20 mA(max)20~40M : 50 mA(max)
Adjustable
FrequencyRange
+/-50PPM ~ +/-250PPM
ControlVoltageRange
0 ~ 3.3 V / 0 ~ 5 V
Slope
Positive
Linearity
+/- 10%
StorageTemperatureRange
-50 ~ +90℃
Application
Mobile Communication Equipments, 3G Communication , Wireless
Base Station, Repeater , GPS , GSM,CDMA ,SDH/SONT, PDH , Instruments
and meters with high precision ，Electricity Measure Equipments
, Specialized Network, Military Radio Stations and Radar Equipments,
Remote Sensing and Consumer Electronics Products Etc .
Feature
High Stability ,Low Aging ,Small Size , Wide Temperature
Range
